Buy INA114 IC – Precision Instrumentation Amplifier IC
₹515.00
The INA114 is a low cost, general purpose instrumentation amplifier offering excellent accuracy.
Its versatile 3-op amp design and small size make it ideal for a wide range of applications. A single external resistor sets any gain from 1 to 10,000. Internal input protection can withstand up to ±40V without damage.
The INA114 is laser trimmed for very low offset voltage (50µV), drift (0.25µV/°C) and high common-mode rejection (115dB at G = 1000). It operates with power supplies as low as ±2.25V, allowing use in battery operated and single 5V supply systems. Quiescent current is 3mA maximum. INA114 Instrumentation Amplifier is available in 8-pin plastic and SOL-16 surface-mount packages. Both are specified for the –40°C to +85°C temperature range.
Order fulfilled by Just Electronics, your reliable partner for all your electronic component needs for Industrial & Educational Purposes.
FEATURES
-
LOW OFFSET VOLTAGE : 50µV max
-
LOW DRIFT : 0.25µV/°C max
-
LOW INPUT BIAS CURRENT : 2nA max
-
HIGH COMMON-MODE REJECTION : 115dB min
-
INPUT OVER-VOLTAGE PROTECTION : ±40V
-
WIDE SUPPLY RANGE : ±2.25 to ±18V
-
LOW QUIESCENT CURRENT : 3mA max
-
8-PIN PLASTIC AND SOL-16
APPLICATION OF INA114
-
BRIDGE AMPLIFIER
-
THERMOCOUPLE AMPLIFIER
-
RTD SENSOR AMPLIFIER
-
MEDICAL INSTRUMENTATION
-
DATA ACQUISITION
